Specifications of Conveyor Belt
| Parameter | Details |
| Belt Type | Flat / Cleated / Modular / Inclined / Roller |
| Material | PVC / PU / Rubber / Nylon / Steel Cord |
| Belt Width | 300 mm – 2000 mm (customizable) |
| Belt Length | 1 m – 100 m+ (depends on application) |
| Belt Thickness | 2 mm – 20 mm |
| Load Capacity | 50 – 2000 kg/hr (or more based on design) |
| Speed | 0.1 – 3 m/s (adjustable with VFD) |
| Drive Type | Gear Motor / Drum Motor |
| Motor Power | 0.5 HP – 5 HP |
| Voltage | 220V / 380V / 415V (AC) |
| Frame Material | MS (Powder Coated) / SS 304 / Aluminum |
| Roller Type | Steel / PVC / Rubber Coated |
| Inclination Angle | 0° – 45° (for inclined conveyors) |
| Operating Temperature | -10°C to 80°C (depends on belt type) |
| Noise Level | ≤ 70 dB |
| Control System | Manual / PLC / VFD-based Speed Control |
